SHARK ANTENNA
LTE / Sub-6 5G Antenna
High-performance MIMO antenna for 4G LTE / 5G, DAB+, WLAN and GPS
This high-performance MIMO antenna was specifically designed for camping and ensures a reliable and stable connection wherever you are. Thanks to its wide frequency range of 698 to 960 MHz, 1710 to 2800 MHz, and 3300 to 3800 MHz, it is ideal for receiving 4G LTE and 5G signals. With a signal gain of +13 dBi, it significantly improves signal strength and enables optimal network coverage.
In addition to mobile internet connectivity, the antenna also supports Wi-Fi in the 2.4 GHz and 5 GHz bands, allowing for a stable wireless connection. A powerful GPS module is also integrated, enabling precise location tracking with a frequency range of 1,575 MHz and a signal gain of +28 dBi.
For easy installation, the antenna comes with seven RG-174 cables, each 1 meter long, which can optionally be extended by 1 or 2 meters. The connectors are SMA (male) plugs, ensuring broad compatibility.
Thanks to its robust construction and IP69K protection rating, the antenna is particularly resistant to dust, water, and extreme temperatures from -40°C to 85°C. With compact dimensions of 188 x 68 x 76 mm and a weight of 330 g, it can be easily attached to motorhomes, campervans, or other vehicles using the simple magnetic mount.
This antenna offers not only mobile and Wi-Fi reception but also the bonus of DAB+ reception. This ensures optimal digital radio reception even when traveling. It gives you the freedom to be online at all times and enjoy your adventure without restrictions.
Information
4G / LTE / 5G
MIMO frequency range: 698 - 960 MHz, 1710 - 2800 MHz, 3300 - 3800 MHz
Signal gain: 698 - 960 MHz up to +5 dBi; 1710 - 2800 MHz up to +9 dBi; 3300 - 3800 MHz up to +10 dBi
Cable: 4 x RG174, length 1 m (1 m or 2 m cable extension optionally available)
Connectors: SMA male
WLAN 2.4 GHz / 5 GHz
Signal gain: 2.4 – 2.5 GHz up to +3 dBi, 5.15 – 5.85 GHz up to +13 dBi
Cable: 2 x RG174, length 1 m (1 m or 2 m cable extension optionally available)
Connector: RP-SMA male
GPS
Frequency range: 1,562 - 1,612 MHz
Signal gain: +28 +/-2 dBi
Cable: 1 x RG174, length 1 m (1 m or 2 m cable extension optionally available)
Connector: SMA male
DAB+ / DVB-T
VHF signal gain: 14 dBi, UHF signal gain: 10 dBi
Operating temperature: -40°C - 80°C
Protection class: IP69K (except cable outlet)
Dimensions: 185 x 60 x 55 mm
Weight: 330g
